Meraki MV63

SKU : MV63-HW

Regular price $970.00 $1,869.14 48% OFF


/
Available to order
Spent $199.00 more to get free shipping

COMPLETE THE LOOK

Outdoor wide-angle dome camera with 256GB storage

8.4MP outdoor dome camera with IR illumination and cloud management.

Meraki MV63

Meraki MV63

$970.00

Ask about Meraki MV63

Need bulk pricing, configuration help, or a license tier quote?

Skip the cart and get a written quote from a Cisco-certified specialist — usually within 4 business hours. Includes pricing, ETA, and a recommendation if you need one.

Quoting on Meraki MV63  ·  Same-day response, no call queue

Request a Quote →
Product Details

The Meraki MV63 is an outdoor wide-angle fixed lens mini dome camera with 256GB onboard storage, delivering 8.4MP video with Smart Codec encoding.

Key Specifications

  • Meraki cameras
  • 8.4MP video recording with Smart Codec encoding
  • 256GB high write endurance solid-state storage
  • Fixed focused lens, IR illumination up to 20 m or 66 ft
  • 802.11ac wireless
  • Microphone with external hardware switch for audio recording
  • People and vehicle detection powered by machine-learning technology
  • Cloud management via Meraki dashboard
  • Object detection powered by advanced machine learning

Safe, smart, and secure

Granular access controls
  • Control who can view live and historical footage
  • Limit access to video exporting
  • Grant access to individual cameras or by device tag
Cloud management
  • Network-wide visibility and control
  • Stream local or remote - the cloud automatically routes the video stream
  • One-click firmware updates
  • Automatic cloud archival
Advanced analytics
  • Person and vehicle detection built in
  • Search video by object type or time
  • Heat maps and area occupancy monitoring
  • Motion-based alerts and notifications
Easy installation
  • Zero-touch cloud provisioning
  • Power over Ethernet (PoE) or adapter
  • Integrated onboard storage - no NVR required
  • Mount accessories included
Datasheet
Specifications
Fixed lens mini-dome camera with 8MP Image Sensor Compact form factor with 101.3° horizontal FoV More detailed information with up to 4K resolution Low bandwidth Consumption for recording and streaming using Smartcodec encoding Guaranteed days of video with Smart Retention Night vision with IR illumination up to 20 m (66 ft) IK10+ and IP67 for deployment in outdoor and demanding environments Intelligent motion indexing with search engine Built-in search tools like motion search, motion recap, motion heatmaps and Attribute Search.Built-in analytics like Line Crossing, Area Occupancy, MV sense and Custom Computer-Vision capabilities
Machine-learning capability for intelligent object detection
Secure video access to ensure privacy with role-based user accounts
Cloud-augmented edge storage for minimal physical infrastructure
Built-in automatic security with secure boot and signed firmware, backed by a hardware security chip
Suitable for deployments of all sizes, from 1-10,000+ cameras
NDAA Compliant
EN 50155 Railway Compliance
Category
Specifications
Camera1/2.8″ 8.41MP (3854x2176) progressive CMOS backlit image sensor
256 GB high-endurance solid-state storage (MV63)
512 GB high-endurance solid-state storage (MV63M)
1 TB high-endurance solid-state storage (MV63X)
3.3 mm focal length
f/2.0 aperture
Field of view: Diagonal: 119.7, Horizontal:101.3, Vertical: 54.4
1/30 second to 1/32,000 second shutter speed
Auto day/night capable
Built-in IR illuminators, effective up to 20 m (66 ft)
Heating elements
Video4K video recording (3840x2160) with H.264 Smart Codec, up to 15fps
4MP (2560 x 1440) with H.264 Smart Codec, up to 24fps
1080p (1920x1080) with H.264 Smart Codec, up to 24fps
High dynamic range (HDR)
Cloud augmented edge storage (locally stored video, metadata in the cloud)
Optimized retention settings (scheduling, motion-based) for variable retention
Direct live streaming with no client software (native browser playback)*
Stream video anywhere with automatic cloud proxy
Audio recording supported with three (3) built-in microphones
DORI Specifications (Maximum Resolution)Detect (25 ppm/ 8 ppf)
86.9 m / 285.1 ft
Observe (63 ppm/ 19 ppf)
34.5 m / 113.1 ft
Recognize (125 ppm/ 38 ppf)
17.4 m / 57.1 ft
Identify (250 ppm/ 76 ppf)
8.7 m / 28.5 ft
Networking and wireless1x 10/100/1000BASE-T Ethernet (RJ45)
DSCP traffic marking
Supported frequency bands (country-specific restrictions apply):
2.4 GHz 802.11b/g/n radio
2.412 - 2.484 GHz
5 GHz 802.11a/n/ac radio
5.150 - 5.250 GHz (UNII-1)
5.250 - 5.350 GHz (UNII-2)
5.470 - 5.600, 5.660 - 5.725 GHz (UNII-2e)
5.725 - 5.825 GHz (UNII-3)
1x1 with one spatial stream
20, 40, and 80 MHz channels (802.11ac)
Up to 256 QAM on 5 GHz band
Integrated omnidirectional antennas (6.3 dBi gain at 5 GHz)
MT Gateway Support for all MT sensors
PowerPower consumption 25.5W maximum via 802.3at PoE
EnvironmentTemperature: -40°C to 50°C (-40°F to 122°F)**
Data and network securityFull disk encryption (AES-256)
Automatically purchased and provisioned TLS certificates (publicly signed)
Management encryption and two-factor authentication
Wireless security:
WPA3-Personal (PSK / SAE)
WPA, WPA2-PSK, WPA2-Enterprise with 802.1X EAP-TTLS TKIP and AES encryption
Physical characteristicsDimension: 130.98 mm x 95 mm (diameter x height)
Weight: 920 grams
Fixed lens
Ethernet Connector with RJ45 Interface
Multicolor, multifunction status LED
External microphone switch
Reset button
WarrantyFive-year hardware warranty with advanced replacement
HardwareMV63-HW: Fixed lens outdoor mini-dome camera with 256 GB storage
MV63M-HW: Fixed lens outdoor mini-dome camera with 512 GB storage
MV63X-HW: Fixed lens outdoor mini-dome camera with 1 TB storage
LicensingLIC-MV-XYR: Meraki MV Enterprise license (X = 1, 3, 5, 7, 10 years)
[Optional] LIC-MV-SEN-XYR: Meraki MV Sense license (X = 1, 3, 5, 7, 10 years)
[Optional] LIC-MV-CA30-XY: MV Cloud Archive license (X = 1, 3, 5 years)
[Optional] LIC-MV-CA90-XY: MV Cloud Archive license (X = 1, 3, 5 years)
[Optional] LIC-MV-CA180-XY: MV Cloud Archive license (X = 1, 3, 5 years)
[Optional] LIC-MV-CA365-XY: MV Cloud Archive license (X = 1, 3, 5 years)
AccessoriesMA-MNT-MV-18: Mounting plate replacement kit
MA-MNT-MV-28: Pole mount
MA-MNT-MV-38: Wall-mount L-bracket
MA-MNT-MV-48: Wall-mount arm bracket
MA-MNT-MV-58: Conduit back box
MA-MNT-MV-68: T-rail adapter
MA-MNT-MV-88: Corner mount
MA-MNT-MV-78: Telescopic mount
MA-INJ-4: 802.3at power over Ethernet injector
MA-PWR-MV-LV: Low voltage 12V DC/24V AC input
In the boxQuick-start and installation guide
MV camera hardware
Wall-mounting kit
