Meraki MV93X

SKU : MV93X-HW

Regular price $1,364.00 ~~$2,176.00~~ 37% OFF

Add to Cart

Note: A Meraki license is required to operate this device. Select “Hardware Only” only if you already have a license.

Spent $199.00 more to get free shipping

Estimated delivery between 11 June - 17 June.

COMPLETE THE LOOK

Outdoor fisheye camera with 1TB onboard storage

With 2880x2880 resolution and 360 views, MV93X is ideal for situational awareness and wide coverage of an area.

Meraki MV93X

$1,364.00

Ask about Meraki MV93X

Product Details

The Meraki MV93X is an outdoor fisheye camera with 1TB storage for extended retention and 12.4 MP resolution at up to 2880x2880.

Key Specifications

Meraki cameras
12.4 MP sensor with up to 2880x2880 recording
1 TB high write endurance solid-state storage
180-degree horizontal and vertical fields of view
802.11ac wireless
Microphone with external hardware switch for audio recording
People and vehicle detection powered by machine-learning technology
Cloud management via Meraki dashboard

Safe, smart, and secure

Granular access controls

Control who can view live and historical footage
Limit access to video exporting
Grant access to individual cameras or by device tag

Cloud management

Network-wide visibility and control
Stream local or remote - the cloud automatically routes the video stream
One-click firmware updates
Automatic cloud archival

Advanced analytics

Person and vehicle detection built in
Search video by object type or time
Heat maps and area occupancy monitoring
Motion-based alerts and notifications

Easy installation

Zero-touch cloud provisioning
Power over Ethernet (PoE) or adapter
Integrated onboard storage - no NVR required
Mount accessories included

Datasheet

Specifications
360° fisheye lens camera Compact form factor with 180° horizontal and vertical FoV Large level of detail with up to 2880x2880 video resolution Guaranteed days of video with Smart Retention Night vision with IR illumination up to 20 m / 66 ft IK10+ and IP67 rated for deployment in more demanding environments Intelligent motion indexing with search engine Built-in analytics like Motion Search, Motion Recap, and Motion Heatmaps	Digital Pan-Tilt-Zoom (DPTZ) mode for live & historical video Machine learning capability for intelligent object detection Role-based user accounts provide secure video access and ensure privacy Cloud-augmented edge storage for minimal physical infrastructure Built-in automatic security with secure boot and signed firmware, backed by a hardware security chip Suitable for deployments of all sizes, 1-10,000+ cameras NDAA Compliant EN 50155 Railway Compliance
Category
Specifications
Camera
1/2.3″ 12.4MP (4072x3046) progressive CMOS image sensor High-performance fisheye lens 256GB high-endurance solid-state storage (MV93) 512GB high-endurance solid-state storage (MV93M) 1TB high-endurance solid-state storage (MV93X) 1.6 mm focal length f/2.0 aperture Field of view: horizontal 180°, vertical 180° 1/30 second to 1/32,000 second shutter speed Auto day/night mode switching capable Built-in IR illuminators, effective up to 20 m (66 ft) Heating elements
Video
8MP video recording (2880x2880) with H.264 Smart Codec, up to 15fps 4.2MP (2112x2112) 360° overview with H.264 Smart Codec, up to 24fps 1MP (1080x1080) 360° overview with H.264 Smart Codec, up to 24fps High dynamic range (HDR) Cloud-augmented edge storage (locally stored video; metadata in the cloud) Optimized retention settings (scheduling, motion-based) for variable retention Direct live streaming with no client software (native browser playback)* Stream video anywhere with automatic cloud proxy Audio recording supported with three (3) built-in microphones
DORI Specifications (Maximum Resolution)
Detect (25 ppm/ 8 ppf) 36.7 m / 120.4 ft Observe (63 ppm/ 19 ppf) 14.6 m / 47.9 ft Recognize (125 ppm/ 38 ppf) 7.3 m / 23.9 ft Identify (250 ppm/ 76 ppf) 3.7 m / 12.1 ft
Networking and wireless
1x 10/100/1000BASE-T Ethernet (RJ45) DSCP traffic marking Supported frequency bands (country-specific restrictions apply): 2.4 GHz 802.11b/g/n radio 2.412 - 2.484 GHz 5 GHz 802.11a/n/ac radio 5.150 - 5.250 GHz (UNII-1) 5.250 - 5.350 GHz (UNII-2) 5.470 - 5.600, 5.660 - 5.725 GHz (UNII-2e) 5.725 - 5.825 GHz (UNII-3) 1x1 with one spatial stream 20, 40, and 80 MHz channels (802.11ac) Up to 256 QAM on 5 GHz band Integrated omnidirectional antennas (6.3 dBi gain at 5 GHz) MT Gateway Support for all MT sensors
Power
Power consumption 25.5W maximum via 802.3at PoE
Environment
Temperature: -40°C to 50°C (-40°F to 122°F)**
Data and network security
Full disk encryption (AES-256) Automatically purchased and provisioned TLS certificates (publicly signed) Management encryption and two-factor authentication Wireless security: WPA3-Personal (PSK / SAE) WPA, WPA2-PSK, WPA2-Enterprise with 802.1X EAP-TTLS TKIP and AES encryption
Physical characteristics
Dimension: 137.68mm x 67.9mm (diameter x height) Weight: 1050 grams Fisheye lens Female RJ45 Ethernet connector Multicolor, multifunction status LED External microphone switch Reset button
Warranty
Five-year hardware warranty with advanced replacement
Hardware
MV93-HW: 360° fisheye lens outdoor camera with 256 GB storage MV93M-HW: 360° fisheye lens outdoor camera with 512 GB storage MV93X-HW: 360° fisheye lens outdoor camera with 1 TB storage
Licensing
LIC-MV-XYR: Meraki MV Enterprise license (X = 1, 3, 5, 7, 10 years) [Optional] LIC-MV-SEN-XYR: Meraki MV Sense license (X = 1, 3, 5, 7, 10 years) [Optional] LIC-MV-CA30-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA90-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA180-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA365-XY: MV Cloud Archive license (X = 1, 3, 5 years)
Accessories
MA-MNT-MV-18: Mounting plate replacement kit MA-MNT-MV-28: Pole mount MA-MNT-MV-38: Wall-mount L-bracket MA-MNT-MV-48: Wall-mount arm bracket MA-MNT-MV-58: Conduit back box MA-MNT-MV-68: T-rail adapter MA-MNT-MV-88: Corner mount MA-MNT-MV-78: Telescopic mount MA-INJ-4: 802.3at power over Ethernet injector MA-PWR-MV-LV: Low voltage 12V DC/24V AC input PoE injector
In the box
Quick-start and installation guide MV camera hardware Ceiling/Wall mounting kit
