Meraki MV63X

SKU : MV63X-HW

Regular price $1,293.00 ~~$2,176.00~~ 40% OFF

Add to Cart

Note: A Meraki license is required to operate this device. Select “Hardware Only” only if you already have a license.

Spent $199.00 more to get free shipping

Estimated delivery between 11 June - 17 June.

COMPLETE THE LOOK

Outdoor wide-angle dome camera with 1TB storage

Fixed lens outdoor dome camera with 8.4MP resolution and 1TB SSD for up to 120 days of extended video retention.

Meraki MV63X

$1,293.00

Ask about Meraki MV63X

Product Details

See why the Cisco Meraki MV63X outdoor security camera is the right cloud-managed, smart camera solution for protecting your business or organization.

Key Specifications

1 TB high write endurance solid-state storage
4K video recording with smart codec encoding
Fixed lens with IR illumination up to 20 m or 66 ft
802.11ac wireless
Microphone with external hardware switch for audio recording
Control who can view live and historical footage
Limit access to video exporting
Grant access to individual cameras or by device tag
Network-wide visibility and control
Stream local or remote the cloud automatically routes the video stream
Create and organize video walls

Safe, smart, and secure

Granular access controls

Control who can view live and historical footage
Limit access to video exporting
Grant access to individual cameras or by device tag

Cloud management

Network-wide visibility and control
Stream local or remote - the cloud automatically routes the video stream
One-click firmware updates
Automatic cloud archival

Advanced analytics

Person and vehicle detection built in
Search video by object type or time
Heat maps and area occupancy monitoring
Motion-based alerts and notifications

Easy installation

Zero-touch cloud provisioning
Power over Ethernet (PoE) or adapter
Integrated onboard storage - no NVR required
Mount accessories included

Datasheet

Specifications
Fixed lens mini-dome camera with 8MP Image Sensor Compact form factor with 101.3° horizontal FoV More detailed information with up to 4K resolution Low bandwidth Consumption for recording and streaming using Smartcodec encoding Guaranteed days of video with Smart Retention Night vision with IR illumination up to 20 m (66 ft) IK10+ and IP67 for deployment in outdoor and demanding environments Intelligent motion indexing with search engine Built-in search tools like motion search, motion recap, motion heatmaps and Attribute Search.	Built-in analytics like Line Crossing, Area Occupancy, MV sense and Custom Computer-Vision capabilities Machine-learning capability for intelligent object detection Secure video access to ensure privacy with role-based user accounts Cloud-augmented edge storage for minimal physical infrastructure Built-in automatic security with secure boot and signed firmware, backed by a hardware security chip Suitable for deployments of all sizes, from 1-10,000+ cameras NDAA Compliant EN 50155 Railway Compliance
Category
Specifications
Camera	1/2.8″ 8.41MP (3854x2176) progressive CMOS backlit image sensor 256 GB high-endurance solid-state storage (MV63) 512 GB high-endurance solid-state storage (MV63M) 1 TB high-endurance solid-state storage (MV63X) 3.3 mm focal length f/2.0 aperture Field of view: Diagonal: 119.7, Horizontal:101.3, Vertical: 54.4 1/30 second to 1/32,000 second shutter speed Auto day/night capable Built-in IR illuminators, effective up to 20 m (66 ft) Heating elements
Video	4K video recording (3840x2160) with H.264 Smart Codec, up to 15fps 4MP (2560 x 1440) with H.264 Smart Codec, up to 24fps 1080p (1920x1080) with H.264 Smart Codec, up to 24fps High dynamic range (HDR) Cloud augmented edge storage (locally stored video, metadata in the cloud) Optimized retention settings (scheduling, motion-based) for variable retention Direct live streaming with no client software (native browser playback)* Stream video anywhere with automatic cloud proxy Audio recording supported with three (3) built-in microphones
DORI Specifications (Maximum Resolution)	Detect (25 ppm/ 8 ppf) 86.9 m / 285.1 ft Observe (63 ppm/ 19 ppf) 34.5 m / 113.1 ft Recognize (125 ppm/ 38 ppf) 17.4 m / 57.1 ft Identify (250 ppm/ 76 ppf) 8.7 m / 28.5 ft
Networking and wireless	1x 10/100/1000BASE-T Ethernet (RJ45) DSCP traffic marking Supported frequency bands (country-specific restrictions apply): 2.4 GHz 802.11b/g/n radio 2.412 - 2.484 GHz 5 GHz 802.11a/n/ac radio 5.150 - 5.250 GHz (UNII-1) 5.250 - 5.350 GHz (UNII-2) 5.470 - 5.600, 5.660 - 5.725 GHz (UNII-2e) 5.725 - 5.825 GHz (UNII-3) 1x1 with one spatial stream 20, 40, and 80 MHz channels (802.11ac) Up to 256 QAM on 5 GHz band Integrated omnidirectional antennas (6.3 dBi gain at 5 GHz) MT Gateway Support for all MT sensors
Power	Power consumption 25.5W maximum via 802.3at PoE
Environment	Temperature: -40°C to 50°C (-40°F to 122°F)**
Data and network security	Full disk encryption (AES-256) Automatically purchased and provisioned TLS certificates (publicly signed) Management encryption and two-factor authentication Wireless security: WPA3-Personal (PSK / SAE) WPA, WPA2-PSK, WPA2-Enterprise with 802.1X EAP-TTLS TKIP and AES encryption
Physical characteristics	Dimension: 130.98 mm x 95 mm (diameter x height) Weight: 920 grams Fixed lens Ethernet Connector with RJ45 Interface Multicolor, multifunction status LED External microphone switch Reset button
Warranty	Five-year hardware warranty with advanced replacement
Hardware	MV63-HW: Fixed lens outdoor mini-dome camera with 256 GB storage MV63M-HW: Fixed lens outdoor mini-dome camera with 512 GB storage MV63X-HW: Fixed lens outdoor mini-dome camera with 1 TB storage
Licensing	LIC-MV-XYR: Meraki MV Enterprise license (X = 1, 3, 5, 7, 10 years) [Optional] LIC-MV-SEN-XYR: Meraki MV Sense license (X = 1, 3, 5, 7, 10 years) [Optional] LIC-MV-CA30-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA90-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA180-XY: MV Cloud Archive license (X = 1, 3, 5 years) [Optional] LIC-MV-CA365-XY: MV Cloud Archive license (X = 1, 3, 5 years)
Accessories	MA-MNT-MV-18: Mounting plate replacement kit MA-MNT-MV-28: Pole mount MA-MNT-MV-38: Wall-mount L-bracket MA-MNT-MV-48: Wall-mount arm bracket MA-MNT-MV-58: Conduit back box MA-MNT-MV-68: T-rail adapter MA-MNT-MV-88: Corner mount MA-MNT-MV-78: Telescopic mount MA-INJ-4: 802.3at power over Ethernet injector MA-PWR-MV-LV: Low voltage 12V DC/24V AC input
In the box	Quick-start and installation guide MV camera hardware Wall-mounting kit
